Name: Non-Inverting Op-Amp Calculator
Author: Eleczia

Non-Inverting Op-Amp Calculator

Vout (V)

Gain (A)

R1 (kΩ)

V1 (Input Lead) (V)

V2 (Offset, optional) (V)

Formula:

These are the equations used for calculation:

$$ V_{out1} = A \cdot V_1 $$ $$ V_{out2} = V_{out} - V_{out1} $$ $$ R_3 = R_1 $$ $$ R_4 = \frac{A \cdot R_3 \cdot V_2}{V_{out2}} $$ $$ R_2 = \frac{A \cdot (R_1 + R_4)}{R_4 \cdot R_1} - R_1 $$
